Jinko Solar JKM-615N-66HL4M-BDV Bifacial Solar Panel
- Power 615
JinkoSolar is one of the world leaders in the solar energy industry, with products used all over the world. By various estimates, roughly every tenth PV module in the world is made by this brand, which confirms its technological edge and…
Description
JinkoSolar is one of the world leaders in the solar energy industry, with products used all over the world. By various estimates, roughly every tenth PV module in the world is made by this brand, which confirms its technological edge and the trust of users.
The JKM615N-66HL4M-BDV model is a modern bifacial module with high efficiency (22.7%), created for maximum electricity generation and long-term operation. Thanks to bifacial generation you get more electricity from the same area. The ultra-strong modern Double Glass panel construction uses 2 mm of tempered glass for maximum strength and resistance to mechanical damage. The solar panel can be used on commercial and industrial facilities and also suits various types of solar power plants.
Panel specifications
- Brand
- Jinko Solar
- Power tolerance, %
- ±3%
- Linear power warranty
- 30 years
- Ingress Protection
- IP68
- TUV connection cables, mm
- 4.0
- Number of cells, pcs
- 132 (66 X 2)
- Number of mounting holes, pcs
- 8
- Efficiency, min., %
- 22,77
- PV module class
- Grade A
- Max. system voltage
- 1500
- Max. current, A
- 25
- Open-circuit voltage
- 48.88
- Voltage at maximum power
- 40,60
- First-year degradation
- 1%
- Power
- 615
- Frame
- material / colour – Anodized aluminium/silver
- Operating temperature, °C
- -40 < t < +85
- Cell size, mm
- 158.75x158.75
- Junction box
- IP68
- Annual degradation over 30 years
- 0,4%
- Glass
- material/thickness, front/rear side, mm – Tempered / 2 / 2
- Short-circuit current
- A 16.02
- Current at maximum power, A
- 15,15
- Cell technology
- N-type
- Panel type
- Monocrystalline BIFACIAL
- Warranty
- 12 years
- Connectors
- MC4 – compatible
