Deye SUN-8K-SG05LP1-EU Hybrid Inverter

Inverters

Deye SUN-8K-SG05LP1-EU Hybrid Inverter

Deye SUN-8K-SG05LP1-EU

  • Power 12800
  • Phases 1
  • MPPT 2/2
  • Ingress Protection IP65

Deye SUN-6K-SG05LP1-EU is a modern single-phase hybrid inverter with a rated power of 6 kW that combines the functions of a grid-tied, off-grid and UPS solution.

Description

Deye SUN-6K-SG05LP1-EU is a modern single-phase hybrid inverter with a rated power of 6 kW that combines the functions of a grid-tied, off-grid and UPS solution. It is created for the most efficient use of solar energy, operation with batteries and the provision of uninterrupted power in a house or at a commercial facility.

Thanks to generator support and flexible settings, the inverter easily adapts to any operating conditions.

Two MPPT controllers ensure stable generation even with different panel orientations or partial shading. This makes it possible to use the potential of the solar power plant to the maximum.

Safety and reliability

  • Protection against short circuit, overvoltage and overheating
  • Reverse polarity monitoring
  • Optional arc fault detection (AFCI)
  • IP65 protection rating (for indoor and outdoor installation)
  • Compliance with IEC/EN standards
Deye SUN-6K-SG05LP1-EU is a versatile solution for building a modern solar power plant with a high level of autonomy. The inverter ensures stable operation, flexible configuration and efficient use of energy, helping to reduce electricity costs and increase energy independence.

Inverter specifications

Brand
Deye
Frequency, Hz
50/60
Input voltage range, V
125~500
Waveform
correct
Dimensions, mm
366×589.5×237
Warranty, months
60
Ingress Protection
IP65
Interface
RS485, WiFi/GPRS (optional)
Efficiency, %
97.6
Country of manufacture
China
Max. voltage, V
500
Max. MPPT tracker current, A
34+34
Max. charge current, A
190
Max. output current, A
26
Model
SUN-8KSG05LP1-EU
MPPT
2/2
MPPT voltage range, V
150~425
Battery voltage, V
48
Rated power, W
8000
Rated input voltage
220
Rated output power in inverter mode
8000
Cooling
intelligent, controlled fan cooling
Phases
1
Power
12800
Operating temperature range, °C
-25...60
Inverter type
hybrid
Input current, A
26+26
Humidity, %
0...100
Output voltage, V
220/230
Output current, A
33.1/36.4
Weight
26.8
